S4-Q24KE3A2

Key Features

• 70% Energy Saving
• 40% Fast Cooling
• Dual Inverter CompresserTM

• Cooling Capacity(Min ~ Rated ~ Max)

  0.90 ~ 6.45 ~ 8.00 kW
  3,070 ~ 22,000 ~ 27,300 Btu/h




• Power Input - Cooling(Min ~ Rated ~ Max)

  340 ~ 1,821 ~ 3,700 W



• Power Input - Heating(Min ~ Rated ~ Max)

  340 ~ 1,998 ~ 3,700 W

• Running Current - Cooling(Min ~ Rated ~ Max)

  1.65 ~ 8.10 ~ 17.00 A



• Running Current - Heating(Min ~ Rated ~ Max)

  1.65 ~ 8.80 ~ 17.00 A

• EER

  3.54 W/W
  12.08 (Btu/h)/W



• COP

  3.55 W/W
  12.11 (Btu/h)/W

• Available Voltage Range

  187 ~ 253 V



• Power Factor - Cooling / Heating

  97.7% / 98.7%

• Indoor - Sound Pressure Level(Cooling, H / M / L / SL)

  47 / 42 / 37 / 28 dB(A)



• Indoor - Sound Pressure Level(Heating, H / M / L)

  47 / 42 / 37 dB(A)

• Indoor - Dimensions (W × H × D) - Net

  998 × 330 × 210 mm



• Indoor - Dimensions (W × H × D) - Shipping

  1,080 × 422 × 281 mm

• Indoor - Weight (Net)

  12.6 kg



• Indoor - Weight (Shipping)

  14.3 kg

• Outdoor - Sound Pressure Level(Cooling, Max)

  55 dB(A)



• Outdoor - Sound Pressure Level(Heating, Max)

  55 dB(A)

• Outdoor - Dimensions (W × H × D) - Net

  870 × 650 × 330 mm



• Outdoor - Dimensions (W × H × D) - Shipping

  1,026 × 693 × 446 mm

• Outdoor - Weight(Net)

  47.0 kg



• Outdoor - Weight(Shipping)

  51.0 kg

• Operation Range(Cooling)

  18 ~ 54 ℃ DB



• Operation Range(Heating)

  -5 ~ 18 ℃ WB

• Circuit Breaker

  30A



• Power Supply Cable

  3 × 2.5 No. × ㎟

• Power Supply to Unit

  Outdoor



• Power and Transmission Cable

  4 × 0.75 No. × ㎟

• Between Indoor & Outdoor - Piping Length(Min / Standard / Max)

  3 / 5 / 30 m



• Between Indoor & Outdoor - Piping Length(No Charge)

  7.5 m

• Between Indoor & Outdoor - Max. Elevation Difference

  25 m



• Between Indoor & Outdoor - Piping Connection Heat Insulation

  Both liquid and gas pipes

• Refrigerant - Type

  R410A



• Pre Charge

  1,850g

• Additional Charge

  20g/m



• Tool Code (Chassis) (Indoor / Outdoor)

  SK / U24A

• Compressor (Type)

  Dual Inverter Compressor
